OilMoisture Probe
The game-changer for comprehensive water content analysis
OilMoisture is an online optical sensor that uses infrared technology for water content detection. Now, early diagnosis is possible, reducing potential failures associated with water presence in lubrication and hydraulic systems, to improve machine and process reliability.
Water is one of the most dangerous contaminants for the lubrication of critical systems, not only because its presence may be a symptom of leaks, but also because it acts as a corrosive catalyst to critical machine components and lubricating oil degradation. Our advanced technology is able to measure dissolved, emulsified and free water in your fluid.
Description
• Fluid Temperature
• Water Presence (OilMoisture & OilHealth Probe Max)
• Water PPM & % (OilMoisture & OilHealth Probe Max)
• Degradation
SPECIFICATIONS
| Power supply | 24 VDC |
|---|---|
| Current consumption | <100mA |
| Connectivity | Stand-alone sensor: Modbus RTU (RS485) |
| Output | Water raw detection (1-1000) |
| Oil pressure | Up to 12 bar |
| Operating temperature | From 0 to 80ºC |
| Viscosity range | Up to 680 cSt |
| Hydraulic thread | BSPT Conical 1/2” |
| Materials | Aluminium (optional steel) |
| Protection class | IP65 |
| Certification | CE |
One of the main advantages of the sensor is that it can be installed directly in the lubrication system or the oil sump tank, thus simplifying the integration of the sensor into the machine.
